8″ MMI screen
Audio system and speakers
3 seater
Rooftop included
Tilting rear box
Large-volume storage spaces and removable storage box
45 L fuel tank
4,500lb. winch
Hitch specification: 1,134 kg
14-inch black aluminum alloy rims
12V outlet and fast-charging USB-C port
Side mirrors
LED headlights with integrated turn signals
Engine
Type: 3 cylinder, liquid-cooled, DOHC, 12-valves, 4-strokes
Displacement: 998cc
Bore & Stroke: 80 x 66.2 mm (3.15 x 2,61 in)
Compression: 11.0:1
Engine management: Fuel injected engine
Cooling system: Liquid
Starting: Electric
Battery: 30 Ah
Size / Weight
Length x width x height: 2965 x 1645 x 1945 mm (116.7 x 64.7 x 76.5 in)
Wheelbase: 2060 mm (81.1 in)
Minimum ground clearance: 330 mm (12.9 in)
Minimum turning radius: 4250 mm (167.3 in)
Fuel tank capacity: 45 L (11.8 gal)
Curb weight: 970 kg (2138 lbs)
Payload capacity: 727 kg (1603 lbs)
Towing capacity: 1134 kg (2500 lbs)
Rear cargo capacity: 454 kg (1000 lbs)
Transmission
CFMOTO clutch system: variable transmission
Gear box: L / H / N / R / P (parking lock shift system)
Power train: 2WD / 4WD, locking front differential
Wheels
Front wheels: Aluminum alloy (14 in)
Rear wheels: Aluminum alloy (14 in)
Front tires: AT 29 x 9-14
Rear tires: AT 29 x 11-14
Suspension and steering
Front suspension: Double A-arm independent, hydraulic shock absorber
Front travel: 280 mm (11 in)
Rear suspension: Double A-arm independent, hydraulic shock absorber
Rear travel: 260 mm (10.2 in)
Steering: Electric Power Steering (EPS)
Brakes
Brakes: Four wheel brake disc
